Riello oil burner wiring diagram. Application field wiring riello 530 sec primary control direct line low voltage. Permanent lo light. Application field wiring wiring diagram shown below for standard riello 530 sec primary control box installation note. 3398 2 gb technical data specifications burner and mounting flange dimensions burner components identification fuel no. If this burner is being installed on a packaged unit burner comes with the boiler or furnace then follow the settings on the oem page as settings may differburner is set for a single line system. With a consolidated experience in over 90 years of great successes and innovations thanks to projects and solutions aimed to exploit efficiently all types of energy riello is the italian brand leader in manufacturing systems and technologies for heating and cooling in the residential and professional sector.
Burners on balanced flue systems burner solenoid photo or re position can recirculate flue products motor coil cell resulting in burner recycling if this happens check flue position sealing fault finding logic for control box type 535 seld rdb series oil burners. Electronic air shutter requires a constant 120v power supply to the aux terminal failure to provide this will result in no burner operation or air shutter will not close. C6501010 standard f3 5 manual rev. If this burner is being installed on a packaged unit burner comes with the boiler or furnace then follow the settings on the oem page as settings may differ. Riello 40 series residential oil burners note. The settings in this manual are for retrofit applications.
Riello parts lists diagrams parts list datasheets and diagrams for riello oil burners 24 hour delivery on genuine manufacturer boiler spares 30 day money back guarantee. Internal factory wiring riello 40 f series oil burners equipped with an electronic air shutter internal factory wiring pump valve coil a d i c d ak r tl capaitor see field wiring legend. A brown b white c blue d black 6 120v source. Application field wiring riello 530 sec 24 v. Coil voltage 27 30v dc at ignition 3vdc on running. 2 fuel oil bf3 firing rate effective output 050 to 095 us gph 70000 to 133000 btuh bf5 firing rate effective output 075 to 165 us gph 105000 to 231000 btuh voltage single phase 120v 60hz 10 15.
Worldwide leader in burners production. Riello rdb series oil burners red 05s on red 05s off lockout for false flame signal red 02son red off lockout for max n of recycles red 25s on orange 05s on lockout fan motor failure red steady on lockout for no flame after safety time 05s on green control box internal error. Protrude into the chamber area as excessive heat at burner shut down may damage the end cone. Do not activate burner until proper oil line connections have been made or failure of the pump shaft seal may occur. The settings in this manual are for retrofit applications.
