Auxiliary connection is optional it may be connected to any 12v to 24v constant power source or left unconnected. It is a compact rugged all electronic brake controller and is easily installed with the connection of four wires and the mounting bracket supplied.
Diagram Based Wiring Diagram For 6 Pin Trailer Connection
Gsl brake controller wiring diagram. Gsl electronics gsl warrants that its products will under normal use and service be free of defects in material and workmanship for a. Return to the duplex cable under the hood where the brake wire now white needs to be separated from the 12 volt hot lead black. Blue brake wire must be connected directly to the trailer brake wire. Elecbrakes is designed to operate 1 to 2 braked axles. Easily adjustable via the remote control which can be located up to 1m from the controller. Secure the brake controller into the mounting bracket.
Installing a brake controller involves disconnecting the vehicle battery mounting the brake controller onto dash and plugging the unit in with a vehicle specific wiring harness. The four wires on the brake controller will be connected shortly. Wiring diagram to remote control black blue white red to vehicle brake switch cold side. Wiring instructions for electronic brake controls pn 4399 rev k generic wiring diagram read this first. Ebc12 ebc24 digital display slide override with gradual progression multi level digital ramping rbc12 rbc24 compact discreete remote mounting brake controller. In this guide we cover step by step how to install a brake controller.
Keep these instructions with the brake control for future reference. Check them out today. Available in both 12v and 24v gsls rbc range eliminates the need for a separate reducer on 24v systems. The brake control must be installed with a 12 volt negative ground. Read and follow all instructions carefully before wiring brake control. 20 stage click knob with push override.
Electric brake controller wiring diagram. Redarc electronics have a large database of faqs tech tips wiring diagrams and how to guides. If your vehicle is not equipped with a plug and play harness you can also splice in wiring for connecting a brake controller. Rbc 12 ng compact discreete remote mounting brake controller. Wiring diagram xle 12 module 15a circuit breaker. Gsls rbc range is a new generation of brake controllers that operate in a pre set braking force utilising microprocessor technology.
Break away systems may be added to the service brake circuit. Xle12 the micro size electronic brake controller is designed. White ground wire is connected to grounded metal part of the trailer. Important facts to remember 1. Red brake light wire powers up the electronic circuit of the module and must be connected to the cold side of the brake light switch. Wiring the 7 way trailer connector and brake controller.
20 stage click knob with backlit led and push override. Brake controller operating instructions please read these instructions before use the xle 12 is a compact rugged all electronic brake controller. The rbc range is a new generation of brake controllers utilising microprocessor based technology.
