Converting generator to alternator wiring diagram. The small wire goes on the terminal marked ind or wl. Bolt the unit on in place of the generator noting that you have removed two wires from the generator a thick one and a thin one push the thick wire with the large connector on either of the large spade connectors usually marked s or on the alternator. Often the insulation on the factory wiring is cracked and frayed inviting short circuits and other electrical problems down the road for wire terminations at components use crimp on ring type wire terminals. We can deal with two wires. Lets talk about wiring. The orange wire with the male connection on it goes to the generator light on the dash.
A simple guide to converting your aircooled vw from dynamo generator to internally regulated alternator. It needs a small wire that goes to the light on the dash and it needs a heavier wire that carries the current out of the alternator and to the rest of the car. Convert vehicle system polarity to negative earth. A relatively modern alternator only needs two wires to do its job. Then at the control box move the fat charging wire from the d terminal to the a terminal and move the small signal wire from the f terminal to the d terminal. Highly recommend running new wiring for the alternator rather than adapting the existing generator wiring.
Two wires isnt intimidating at all. The first thing to note is depending on if you are on 6 volt or 12 volt electrical system will dictate the position of your regulator on your dynamo. The small black wire from the generator is a ground wire to body of vehicle. This schematic shows the trans po voltage regulator attached to the back of the ford alternator.
