Mic wiring can be frustrating enough but when you cant find the right wiring info it is just impossible. Cb mic wiring diagram the diagram below shows the proper wiring connection of 4 wired mic cable.
Mic Wiring
Cobra mic wiring diagram. Daiwa em 500 cobra ca series 1 shield black 2 red. Different manufacturers may use a different way to wire microphone. Cobra standard 5 pin wiring 148 gtl 2000 gtl etc. Stock 1 audio 2 shield 3 receive 4 sw com 5 transmit. Astatic 4 wire 1 shield 2 white 3 red 4 black. There are some radio brands that have the same general wiring such as cobra and uniden but that is not always the case.
Cobra all standard 4 pin models 2 audio 3 transmit 4 receive 2 white 3 red 4 black yellow nc 2 white 3 red 4 black 2 white 3 brown 4 green. The following microphone wiring diagrams are for the majority of cb and 10 meter radios available. For example cobra 4 pin radios are wired 1 shield 2 audio 3 transmit 4 receive while midland 4 pin radios are wired 1 audio 2 shield 3 receive 4 transmit. Wire 5 transmit 1 white 2 shield 3 black 4 blue 5 red yellow nc 1. Astatic 6 wire 1 shield blue 2 white 3 red 4 black yellow nc. Cobra highgear series hg m77 replacement dynamic noise cancelling cb wire mesh grille.
Stock 1 shield 2 audio 3 transmit 4 receive. Astatic 4 wire 1 white 2 nc 3 black 4 shield 5 red. Heavy duty abs shell. A certain wire has an appropriate pin number that is necessary to be followed. To get a good quality cb. The list below offers some microphone wiring information.
Not following the details will cause your household harm. 1 audio 2 shield 3 receive 4 sw. 29ltd schematic diagram 29 ltd classic schematic diagram courtesy of rick jackson mic wiring. Diagrams from owners manual frequency counter frequency counter 85x11 main schematic main schematic 11x17 main schematic 85x11 parts list. Cb radio mic wiring diagram. Fits cobra cb radio models 18 wx.
The list below offers some cb microphone wiring information.
