The list below offers some cb microphone wiring information. Wire 5 transmit 1 white 2 shield 3 black 4 blue 5 red yellow nc 1.
Ca 75 Cobra Power Mike And Related Power Microphones
Cobra power mic wiring diagram. Radio mic wiring diagram. Now well talk about a 5 wired microphone as shown in the diagram below. Intek m 495 power intek m 550 power intek m 760 plus intek m 795 power intek m 799 plus intek m 899 plus interceptor tc 300. Astatic does not assume the responsibility of any damage to either the microphone nor any radio that has been modified to the specifications within this manual. This wiring discussion assumes that you have no schematic for the radio or no information for the mike. There are some radio brands that have the same general wiring such as cobra and uniden but that is not always the case.
To view microphone wiring configuration click on your chosen cb radio. Cb mic wiring diagram. There are three steps when wiring any new mike to your cb. Covering basic circuit theory schematic operation and some part changes to enhance its performance. Will a stock cobra 29 mic work on a magnum s 380 radio. 1 audio 2 shield 3 receive 4 sw.
Cobra all standard 4 pin models 2 audio 3 transmit 4 receive 2 white 3 red 4 black yellow nc 2 white 3 red 4 black 2 white 3 brown 4 green. 4 pin or 5 pin microphone wiring. A certain wire has an appropriate pin number that is necessary to be followed. Not following the details will cause your household harm. Cb radio microphone wiring. If it is a power mic or echo mic make sure there is a battery in it.
The diagram below shows the proper wiring connection of 4 wired mic cable. Although all have been known to work the wirings in this manual are only recommendations by astatic. Wiring the cobra microphones model. 21 25 29 89gtl1000gtlstandard wiring. Cb mic wiring can be frustrating enough but when you cant find the right wiring info it is just impossible. A page about the ca 75 cobra hand held power mike and many other power mikes that use a small 2 stage amp 9v battery and a fet based electret condensor as the mike element based upon this pcb and design.
Cobra 19gtl cobra 19dxiv eu cobra 21xfm19x cobra 148 gtl dx cobra 146 gtl cobra 21 gtl cobra 29 lx eu. Johnny williams 01052020 0650 pm. How to wire any regular or power mike to almost any cb. Determine which pin on the radios mike socket performs which function tx rx audio ground on the cb itself. The chart and image above are correct for these models. 18rv 19x19plus 20plusstandart wiring.
Cobra standard 5 pin wiring 148 gtl 2000 gtl etc.
