8000 rpm face size. Use plug infuse block kit pn 0173611 when installing tachometer with other accessories.
Pioneer Avic F90bt Wiring Diagram Wiring Diagram
Moon tachometer wiring diagram. Ok done the obvious mooneyes site google etc and cant find a wiring diagram for my moon quarter sweep tach. 30 01 10 0704 pm 2. Does anyone have one that could tell me were the wires go. I have double checked wiringearth etc and still it is no good. Then we create a list of 6 combinations of wiring connection. Use plug in connector kit pn 0174732 when installing tachometer only.
The tachometer is configured at the factory for 4 ppr. Back lit self contained chrome plastic cup housing works with any 4 6 8 cylinder engine nostalgic looking half sweep tach with adjustable redline. 3 factorial 3 x 2 x 1 6 combination possibilities. Black green and yellow wire will be connected to. Moon half sweep tachometer only from mooneyes. Tach is approx 6 months old wired correctly etc and has decided that now it dosent want to work.
Apply power to the tach by turning the ignition key to the accessory or on position. The pointer will move to a. Connect the wire from pin 4 to a switched 12 volt or 24 volt source. Use a wiring kit to connect the tachometer to the plug in connector on the remote control or accessory electrical cable. Connect a wire from pin 5 to a constant 12 or 24 volt source. Yer i had a moon tach in my 57 chev worked ok but know what you mean.
The wiring diagram shown is a typical installation. Httpsamznto2rirmf9 thanks for watching. Wiring diagram for moon tach. Compatible with any 4 6 or 8 cylinder engine. For chrysler blue gold and silver boxes ford standard electronic ignitions and most other oem standard cd and electronic ignitions. Negative or body or ground.
Follow this wire to a junction and attach the wire from pin 4 at this junction ie. I think i sort of know but want to make sure. I brought a old sun tach for my 55 chev it doesnt work dam ebay so now ive just brought a new old style auto meter tach with is all steel and chrome and better mounting brackets. Hey all i have a moon tach installed in my 53 f100 runs 400 ford with elec ignition. Refer to diagram d. With no power applied to the tach press and hold the set button.
White red black green grommet. According to the permutation formula will be obtained. Positive as a power source for the tachometer to work. I guess next step is i remove tach and have a look see inside it. A switched 12 or 24 volt wire can be found coming from the ignition switch. Wiring connect the tachometer wires as shown.
Just a little video i made to help you understand the way a tachometer should be wired. 12v battery coil ignition coil tach base can be mounted in either direction for convenient mounting. To change the ppr on tachs with three buttons follow the steps below. Do not start the engine.
