Use cat3 cable 22 awg. This diagram is an example of readers that can be connected to a kt 400.
Kt 400 Controller Ds R10 Hs En Pdf Security Access
Kantech kt 400 wiring diagram. Compatible with all entrapass special corporate and global editions. This family provides enhanced security through end to end aes 128 encryption over rs 485 when used with kantechs kt 1 or newer kt 400 door controllers while it can be also used with any other access controller using wiegand protocol. This battery must be replaced by a kantech technician to avoid any risk of explosion. Kt 400s standalone mode offers basic door security using a simple web browser without the need to connect to a host system. Backup battery provides operation of up to 12 hours but has been tested for 4 hours per section 33 of ul 294 fifth edition. Kt 400 ethernet four door controller maintenance recommendations the kt 400 includes a lithium ion rechargable battery see the kt 400 ethernet four door controller pcb view on page 8.
Tyco international ltd end user license agreement. Connect kantech part number kt acpw led status indicator to the 16 vac black terminals of the kt 400 use kantech part number kt batt 12 battery see note. Iosmart smart cards and multi technology readers provide a cost effective migration from older proximity cards to advanced smart card technology. With an onboard ethernet port an external ip device isnt required. Kt 400 ethernet four door controller installation guide kt 400 ethernet four door controller installation guide vrmversion r008 prodname kt 400 ethernet four door controller doctype installation guide docnumber d29007912r008. Kantech part of tyco security products offers a full suite of feature rich and cost effective access control products that are reliable easy to install and fully scalable.
Power from a kt 300 to vc 485. Kt 400 ethernet four door controller installation manual overview the kt 400 ethernet four door controller is designed to meet the highest standards of access control and point monitoring applications. Alternatively kt 400 can be used with the powerful. Here are the features of the kt 400 ethernet four door controller. Kt 400 ethernet ready four door controller supports eight readers entrapass security management software and can be configured in two user friendly operational modes. Kt 400 can easily be integrated into an existing entrapass system with other kantech controllers kt 1 and kt 300 or basic door security without the need to connect to a host system when in standalone mode providing the foundation for a brand new security installation.
Use 2 conductors 22 awg. Connection between the computer and the controllers. Ul 1076 compliance notice. You cannot connect aba and proximity readers on the same kt 400. Connect the kt 400 to the ethernet via a traditional ethernet cable. Kantech hooking up inputs kt 400 ethernet four door controller r008 hardware installation guide kt 400 ethernet four door controller installation guide vrmversion r008 prodname.
