The epo box should have a set of connections for each device served. An eposhunt trip situation where there are multiple epo switches say three and the shunt trip coil circuit is powered from two phases of the same 480v circuit as powers the power circuit but is stepped down to 120v by transformer ahead of the epo switches and.
Air Lift Suspension Wiring Diagram Wiring Diagram
Epo shunt trip wiring diagram. Several fault conditions can create a situation where the epo will not operate to shut off the circuit. The accessory terminals will accept 2 14 12 alcu. I could not find this anywhere on line. Shunt trip coil epo button push to close the traditional epo circuit is not fail safe however. Electrically from a remote location by application of control voltage to the accessory leads. Be it 24v 48v or 120v.
Shunt trip breaker wiring diagram with epo button. Thanks harry304e for the pertinent information. Moreover the systems are rarely documented. Shunt trip accessories in qob are factory installed only and can not be added to an existing breaker. Any such online diagram for the following variation would also be of interest. Shunt trip breaker wiring diagram this post is about the single wiring diagram of mccb shunt trip breaker.
Power circuits feeding shunt trip breakers are unidentified and unmonitored. Additionally no maintenance bypass switch is installed that would allow the epo to be defeated during routine. There are no shop drawings showing wiring diagrams location of devices and intended sequence of operation. Sump pump installation diagram tripwire diagram shunt breaker wiring epo switch wiring diagramepo switch wiringshunt trip breakerplease provide a field wiriing diagram for connecting an epo in a data center to a trane model xxxxx so that the crac unit will shut down when the epo is engaged. In industrial state electric operator duty is to operate the machinery and his duty is on the front of main panel board. Shunt trip device black wires maximum permissible voltage is 110 of rated for ac 125 for dc.
In the diagram a mccb molded case circuit breaker shown which is wired for 3 phase system. Shunt tr at electrical specifications. Loss of the epo circuit supply voltage loose wiring or conductors in the epo circuit a blown fuse in the epo circuit. You will run these wires to the shunt trip and it should work the same way. The breaker shunt trip coil is controlled by the emergency switch. The shunt trip has coil clearing contacts that open when the voltage is applied so either momentary or maintained contacts can be used to initiate voltage.
In this post i am just tell you about wiring of single epo button with shunt trip mccb breaker. The shunt trip breaker has to be selected and rated to match the box output voltage. Which is also known with the name of kill switch. The shunt trip allows the circuit breaker to be tripped table i.
