Drayton s plan wiring diagram. Probably the highest number of requests draytons technical team receives every week is for help with wiring diagrams using the lwc1 or lwc3 wiring centre. A wiring diagram usually gives counsel nearly the relative outlook and accord of devices and terminals upon the devices to put up to in building or servicing the device. Get free help tips support from top experts on drayton hts3 wiring diagram related issues. This video covers the wiring and electrical operation of an s plan system with two 2 port valves. This diagram shows the wiring layout using the most typical components. Here coloured wires indicate the permanent mains supply to the boiler and programmer.
Wiring diagrams and further information continues below. Spring return 2 valve systems 22mm twinzone s plan etc wiring centre basic links pump boiler. The drayton lwc1 wiring centre has been introduced to meet this requirement. Wiring diagrams probably the highest number of requests draytons technical team receives every week is for help with wiring diagrams using the lwc1 or lwc3 wiring centre. Use boiler manufacturers instructions. The lwc1 is suited to all popular central heating and hot water systems with adequate wiring space terminals and cable.
Boiler h h motorised valves function of leads drayton 22mm 2 port valve 28mm 2 port valve motor auxsw l n brown blue yellgreen orange grey white 28mm only e c no nc 8n e 6 7 54n e 6 716 motor auxsw l n brown e c no nc blue yell. Each installation is different depending on the configuration and the controls used so to try and help as much as possible the tech team has created 24 diagrams covering. Drayton 3 port valve wiring diagram wiring diagram is a simplified enjoyable pictorial representation of an electrical circuit.
