In this video we show you how to select and install the right transformer for your halogen and led lamps that work at 12v. Discussion in electrics uk started by willj23 18 may 2011.
Low Voltage Pool Transformer
Downlight transformer wiring diagram. 23 may 2009. Thank you for watching. Which transformer do i need for my 12v lamps. Unscrew any bolts or screws holding it in place as well and take the unit out. Led downlight kits typically come with a transformer to convert your v power to a voltage power compatible for the light fixture. Because the wiring apart from the fitting end would be unaccessable once the ceiling is up i would rather have them all coming out of 1 junction box so if ever there was a problem it would mean smashing only one hole in the ceiling but is there such a.
The diagram shows how to wire the receiver. Downlights are wired in a radial circuit and so the feed wire goes to the first light in the circuit and then from the first to the second and then from the second to the third etc. To wire a transformer attach a feed to the primary and the load to the secondary its that simple. Hi folks lets say i wanted to fit 8x 240v downlighters from 1 switch lets say in the lounge. The only reason youd need to keep the transformer is if you wanted to use mr16 leds that operate on ac this is a less popular option as you need to make sure the existing transformer is compatible with the leds and if youre dimming them youll need to make sure that the. However the cable between the transformer and the first lamp would have to carry about 85 amps 100w at 12v is about 85a so you might be better off with 1mm cable.
After you have found the transformer disconnect the wiring. The transformer should have a. Help with wiring 12v downlights. What would be the best way of wiring them. Downlights are wired in a radial circuit and so the feed wire goes to the first light in the circuit and then from the first to the second and then from the second to the third etc. This video is about the led downlights installation.
If you were to connect a separate cable from the transformer to each lamp each cable would only be carrying under 2 amps so 075mm would be ok. I am showing how to wire it make a ceiling holes and install 5 downlights on kitchen ceiling. When you get to the last light on the circuit the wire is terminated into the last light and so there will only be one wire at the last light fitting as opposed to. Wiring diagram help replacing inline fan with timed inline fan. Obtain a wiring diagram of your specific unit instead and consider other types of repairs. Step 3 remove the transformer.
