The tls 2 gd2 has a power to lock function. For application and wiring diagrams see safety applications and wiring diagrams.
Guard Locking Switches Electrical Connector Switch Free
Tls2 gd2 wiring diagram. With an 8 pin micro connector not all contacts are connected. Typical wiring diagrams description frs21 frs2 frs20 2 nc. Gd2 standard 440g t27251 440g t27169 440g t27234 ³. Dimensions are not intended to be used for installation purposes. This is so both contacts are open and closed at the same time and. For special applications the choice of device type is.
In the wiring diagram the tls3 gd2 interlock is connected to input points 0203. 46 di emd mt gd2 grip enabling switch jog powerflex 70 2 3 d 0 48 di emd tls1 gd2 trojan t15 e stop 100s c 3 4 e 0. Red switches tls1 tls2 tls3 contact configuration jumper between 12 41 jumper between 12 41 and 22 51 contact action. Tls2 gd2 application note page 3 of 4 5 example schematic a the following is an example schematic. Tls2 gd2 tls2 gd2 wiring diagram datasheet cross reference circuit and application notes in pdf format. Connection systems description 8 pin micro m12 12 wire.
Typical wiring diagrams description color function no. The 12 wire cordset 889m f12ah 9must be used and for the tls1 and tls2. To monitor independently the safety contacts and the solenoid feedback tl s 1 2 and 3. Read this document and the documents listed in the additional resources section about installation configuration and operation of this equipment before you install configure operate or maintain this product. Each type typical wiring diagrams description frs21 frs2 frs20 2 nc. Two tls2 gd2 interlocks are connected in series to an msr safety relay.
Wiring diagrams 8 recommended relays 10 maintenance 10 declaration of conformity 10 important save these instructions for future use target actuator tlszrl gd2 target switch alignment marks. For application and wiring diagrams see page power. Guard locking interlocks tls1 gd2 datasheet tls1 gd2 circuit tls1 gd2 data sheet. See typical wiring diagrams on page 3 45 for wiring details. Since this is a dual channel circuit with two normally closed contacts set the operation parameter 57 to equivalent. In the wiring diagrams that are shown in this publication the type of allen bradley guardmaster device is shown as an example to illustrate the circuit principle.
The jumper between 12¼41 m ust be removed. Of pins 8 pin micro m12 2 24v dc 1 aux 7 0v 6 safety b 3 lock command 8 safety a 4 safety b 5 safety a. Users are required to. Double click the input points 0203 line. Allen bradley alldatasheet datasheet datasheet search site for electronic components and semiconductors integrated circuits diodes triacs and other semiconductors. 1 2 opto electronics 3 interlock switches 4 5 approximate dimensions dimensions are shown in mm in.
2 rockwell automation publication 440g in016a en p october 2017 tlszrl gd2 guard locking switch. The tls2 gd2 is generally used in applications where the machine is locked only during the machine cycle and the following is an example schematic.
